Project

Parameter

Project

Parameter

Voltage

(V/Hz)380/50

Work efficiency

1 block / (38 seconds)

Aluminum frame height

3300-50(mm)

Work table height

(mm)900±50

Maximum group frame dimensions

2000X1100X（30-50）mm

Group box precision

The difference in edge size is ± 0.5mm

Diagonal size difference ± 1.0mm

Minimum group frame dimensions

1300X800X（30-50）mm

Working pressure

0.6Mpa~0.8Mpa

Installed total power

（kw）7

Whole line weight

（kg）3400
